Specifications:
Displacement: 20
cc
Weight: 1.9 Lb. / 30oz
(includes muffler and ignition)
Output: 2.5 hp @ 9,000
rpm
Thrust: 6kg
@ 100M (13.2 lbs) ~ 5.3kg @ 1800m (11.6 lbs)
Requires: unleaded
gasoline 91-93 octane, oil 1:30 - 1:35, ignition battery (
4.8V-8.4V)
Suggested Propellers: 14x10,
15x8, 16x6, 17x6
|
Technical
Data:
Ignition Battery: 4.8-8.4V
Ignition
Compression Ratio: 10.5:1
Gas/Oil Mix: 30:1
Replacement Spark Plug: CM6
Weight Breakdown: Engine:
23.6 oz (670 g); Muffler: 2.1 oz (60 g); Ignition: 4.9 oz
(140g)
|
